ELUXEO® Endoscopic Imaging System

Overview

Our long-standing experience in medical imaging has allowed Fujifilm’s engineers to develop LED Multi-Light technology, fulfilling the need for enhanced visualization in endoscopy. The ideal output combination of four individual LEDs has been developed to achieve the optimal results in illumination, including White Light as well as the new special light observation modes BLI (Blue Light Imaging) and LCI® (Linked Color Imaging).

Learn More

Technology

Optimal Results In Illumination

Enhanced Visualization In Endoscopy

As one of the world’s largest imaging companies, our long-standing experience in medical imaging has allowed Fujifilm’s engineers to develop LED Multi-Light technology, fulfilling the need for enhanced visualization in endoscopy.

The ideal output combination of four individual LEDs has been developed to achieve optimal results in illumination, including White Light as well as the new special light observation modes BLI (Blue Light Imaging) and LCI® (Linked Color Imaging).

Short Wavelength Absorption

High Intensity Blue-Violet Light

Focusing on the characteristics of short wavelength absorption of hemoglobin (at 410 nm), BLI outputs a high intensity ratio of blue-violet light, to aid high contrast imaging of microvessels.* For additional information on BLI and LCI as well as clinical studies, please visit bli.eu.

Through combination of light spectrum enhancement and advanced signal processing, LCI differentiates the red color spectrum, developed to enhance mucosal visualization.* For additional information on BLI and LCI as well as clinical studies, please visit bli.eu.

* LCI is not intended to replace histopathological sampling as a means of diagnosis



High-resolution and smooth moving image quality is achieved with the CMOS-supported 60 frame progressive scanning technology, less affected by motion blur than the interlaced scanning method.

Positioned at the endoscope tip, the CMOS chip quickly transforms the analog signal to digital, ensuring noiseless and brilliant image transmission.

System Specifications

Model Description
VP-7000 Video Processor Video Output DVI (Resolution: 1280×1024 pixels, 1920×1080 pixels
HD-SDI (Resolution: 1920×1080 pixels)
Irish Mode AUTO/PEAK/AVE
Dimensions (W x H x D) 15.4” x 4.3” x 19.1” (including projection)
Weight 19.8lbs
BL-7000 Light Source Illumination type LEDs
Air supply pump HI/MID/LOW/OFF
Maximum air/water supply pressure 65 kPa
Dimensions (W x H x D) 15.4” x 6.1” x 19.1” (including projection)
Weight 26.5lbs

Intended Use:

The VP-7000 unit is used for endoscopic observation, diagnosis, treatment, and image recording. It is intended to process electronic signals transmitted from a video endoscope (a video camera in an endoscope). This product may be used on all patients requiring endoscopic examination and when using a Fujinon/FUJIFILM medical endoscope and light source together with monitor, recorder and various peripheral devices. BLI (Blue Light Imaging), LCI (Linked Color Imaging) and FICE (Flexible spectral-Imaging Color Enhancement) are adjunctive tools for gastrointestinal endoscopic examination which can be used to supplement Fujifilm white light endoscopy. BLI, LCI and FICE are not intended to replace histopathological sampling as a means of diagnosis.

1The BLI/LCI special light observation modes are only compatible with EC-600WL v2, EG-600WR v2, and 700 series models.
